Hunter Wireless Smart Valve Link
SVC25
$245.00
+ GST
Spend $1,000.00 More to Unlock Free Shipping
PRODUCT INFORMATION
Enable Convenient Wireless Valve Control for ICC2 and HCC Controllers with the Highly Flexible and Easy-To-Install Hunter Wireless Smart Valve Link.
Key Benefits of the Hunter Wireless Smart Valve Link:
- Works with Hunter ICC2 and HCC Controllers, Compatible with Centralus™ and Hydrawise® Irrigation Management Platforms.
- Add up to 54 Valves (+ P/MV) over 650 Metres Line of Sight*.
- Licence-free LoRa Wireless Connections Direct to Valve Box — no Copper Field Wiring Required.
- Wireless Solar Repeater (RPT-E) can Extend or Double Ranges (1 RPT-E Per Controller, Maximum).
- Seamless System Expansion enables connection across Hardscapes and other Obstacles without Wiring.
- Combine with Conventional ICM or EZDS Modules as Needed (54 Stations Plus P/MV Maximum Per Controller).
- Isolation from Lightning or Surge Events in the Field .
- No Field Wires, Wire Breaks, or Tracking.
- No Cutting into Hardscape, Plowing, or Boring Back to the Controller.
Operating Specifications for the HunterWireless Smart Valve Link:
- Low-Profile, Waterproof Valve Box Lid Mount for Field Durability Requires 38 mm Diameter Hole in Valve Box Lid for Installation (Hole Saw Included with WVOM-E Output Module).
- Two-Way Communications confirm Field Performance.
- 433 MHz LoRa Radio.
- 1-, 2-, and 4-Station Configurations to Optimise Field Installations.
- Uses Hunter DC-Latching Solenoids.
- WVL Maximum distance to Solenoid: 30 Metres, depending on Wire Size.
- One or Two 9 VDC Batteries per WVL.
- Solar Recharging Option with SP-WVL.
- Built-in Site Survey and Manual Test Functions ensure successful Operation once Installed in the Field.
- Easy Setup with Free iOS® and Android™ Bluetooth® App.
Approvals:
- FCC, UL, CE, ISED Canada, and RCM, and TDRA Approved.
- WVL Transceivers are IP68 Rated.
- Repeater is IP55 Rated.
Warranty Period: 2 Years.
Key Benefits of the Hunter Wireless Smart Valve Link:
- Works with Hunter ICC2 and HCC Controllers, Compatible with Centralus™ and Hydrawise® Irrigation Management Platforms.
- Add up to 54 Valves (+ P/MV) over 650 Metres Line of Sight*.
- Licence-free LoRa Wireless Connections Direct to Valve Box — no Copper Field Wiring Required.
- Wireless Solar Repeater (RPT-E) can Extend or Double Ranges (1 RPT-E Per Controller, Maximum).
- Seamless System Expansion enables connection across Hardscapes and other Obstacles without Wiring.
- Combine with Conventional ICM or EZDS Modules as Needed (54 Stations Plus P/MV Maximum Per Controller).
- Isolation from Lightning or Surge Events in the Field .
- No Field Wires, Wire Breaks, or Tracking.
- No Cutting into Hardscape, Plowing, or Boring Back to the Controller.
Operating Specifications for the HunterWireless Smart Valve Link:
- Low-Profile, Waterproof Valve Box Lid Mount for Field Durability Requires 38 mm Diameter Hole in Valve Box Lid for Installation (Hole Saw Included with WVOM-E Output Module).
- Two-Way Communications confirm Field Performance.
- 433 MHz LoRa Radio.
- 1-, 2-, and 4-Station Configurations to Optimise Field Installations.
- Uses Hunter DC-Latching Solenoids.
- WVL Maximum distance to Solenoid: 30 Metres, depending on Wire Size.
- One or Two 9 VDC Batteries per WVL.
- Solar Recharging Option with SP-WVL.
- Built-in Site Survey and Manual Test Functions ensure successful Operation once Installed in the Field.
- Easy Setup with Free iOS® and Android™ Bluetooth® App.
Approvals:
- FCC, UL, CE, ISED Canada, and RCM, and TDRA Approved.
- WVL Transceivers are IP68 Rated.
- Repeater is IP55 Rated.
Warranty Period: 2 Years.
